Dissolved gas analysis is becoming increasingly popular in environmental laboratories.
The RSK test, required by the standard EPA method 5035, is a time-consuming and labor-intensive test as it requires manual preparation of sample vials prior to headspace analysis.
EST Analytical’s LGX-50 system fully automates sample preparation for the analysis of methane, ethane, ethene and other compounds present in the headspace of water samples, meeting both the requirements imposed by the EPA methods 5035 and ASTM D8028 for dissolved gas analysis (RSK-175), as well as the need for increasingly robotic laboratory flows.
The analysis is particularly necessary for the control of water discharges from natural gas drilling facilities; in particular the US Environmental Protection Agency requires that the Clean Water Act be applied to surface discharges from shale gas wells.
Key Features:
-
Rugged and reliable
- XYZ design
- High throughput
- Capacity of up to 50 samples
- Compliant with ASTM D8028
- Automatic processing of RSK-175 samples
- The use of optical sensors eliminates errors of: lost vials, incorrect syringe position and incorrect elevator position
- Ease of use
- Intuitive software designed for the end user, allows faster processing of dissolved gas samples
- With remote access, the laboratory can control the samples from any location, if connected to the laboratory server.
